Description
2 * weighing expansion module, 24-bit resolution, supports RS485 Modbus communication.
2 * weighing expansion module, 24-bit resolution, supports RS485 Modbus communication.
Only logged in customers who have purchased this product may leave a review.
| Item | LCM-2WT | |
| Channel | Double channels | |
| Speed | 7.5/10/25/50/60/150/300Hz available | |
| Polarity | Unipolar and bipolar | |
| Non-linearity | ≤0.01% full scale(25°C) | |
| Zero drift | ≤0.2μV/ °C | |
| Gain drift | ≤10ppm/ °C | |
| Excitation Voltage/ load | 5V, load impedance≥200Ω | |
| Sensor sensitivity | 1mV/V-15mV/V | |
| Isolation | Transformer (power supply) and the optical coupler (signal) | |
| Lamp | Power supply lamp, communication lamp | |
| Power supply | 24V±20% 2VA | |
| Operating temperature | 0~60 °C | |
| Storage temperature | -20~80 °C | |
| Dimension | 90(L)x58(W)x80(H) mm | |
| CE Certification | CE marked | |
